Dan Kubin MCi (Mini Cranker with Impact)!

Step up your tattoo game with the new DK MCi – a plug-and-play remastered version of Dan's Mini Cranker from 2011. Updated and refined, it's designed for precision and ease of use, whether you're using a needle on bar or cartridges. With its wide range of versatility and solid hit, it's a must-have for any tattoo artist.

Highlights:

• Steel Frame with HD Light Pink Powder Coat Finish

• Weighted Brass Armature
• Deluxe Kubin Components including DK Thumbs and updated Slide Vise
• Great for Lining and Shading with small to medium groupings, turn voltage up and down for speed and hit adjustment as needed
• Higher voltage between 5 - 7 Volts for most Lining
• Lower Voltage between 3.5 - 5 Volts for most Shading, Color Packing, and Stipple Work

Setup / Specifications:

• Works well with Standard Needle on Bar AND with Cartridges
• Possible to run with Cartridges without any adjustment or tricks, but if you pull your rubber band over the armature it will increase the snap at the tip
• This machine is cartridge friendly, but best to use lower tension cartridges if going that route. (Workhorse Eco Carts and Non Membrane Carts work well with these machines)
• Polarity is not crucial, but will run slightly more efficiently with Positive Down
• The impact screw can be backed off all the way, but ideal to still have a little impact to reduce motor shaft strain
• Turning the impact screw in too much will result in stalling the machine or putting too much strain on the motor.
• Ideal impact is about 1/4-1/2 turn clockwise from the point of zero impact.

Use and Care:

• Please refer to the MCi setup video on my YouTube channel for further clarification - See Link Below

• After a few years, the bearings may dry up. You may use A SINGLE DROP of sewing machine oil on the bearings.  DO NOT FILL THE MOTOR WITH OIL!!
• Keep sterilants away from all moving and electrical components! Sterilants are corrosive and will damage your machine if used carelessly.

Made in the USA!

DK Machines sold by Workhorse are engineered and designed by Dan. Parts are milled in his authorized and trusted machine shop, then assembled by DK certified trained technicians at the Workhorse facility in Michigan. All MCI go through rigorous QC checks and are all ran through our testing machine to lightly break in. One year warranty on all models. All current MCI are serviced by Workhorse, some older models are serviced by Dan or one of his certified technicians found on his website.

Dan Kubin V3/24 Sidewinder!

Highlights:

• 24k Gold Plated Brass Frame and Motor Cover with 24k Gold Plated Hardware (*Finish may vary)

• DK Thumbscrew, new Armature Bar, and updated Stroke Wheel for improved performance
• The renowned rotary liner.  Effortlessly sink any size line by just grazing the skin.
• The motor is the same as the  V2-V4 and V7 Sidewinder, which has proven the test of time.  It has been a favorite of the long time Sidewinder collectors.
• Vice-Lock that easily tightens on nearly any tube
• Great for all varieties of Line Work or as a Fast Shader/Packer

• Timing mark on the cam and frame for setting the impact screw. (Just like the V5 and V6)

• Marked stroke dial so you can easily play with the stroke without fear of losing that sweet spot.  You can’t make it too long or too short

Machine Setup:

• Standard Needle on Bar:
  • Needle Bar Tensioner - when setting up your needle and tube, position needle tensioner in desired position depending on the amount of tension you want to add to the needle bar. Adjust position by loosening the thumbscrew and then tightening when you reach desired tension.
  • Rubber Band alternative setup - Loosen / remove thumbscrew to take the needle tensioner off. Then when setting up the machine, wrap a thick rubber band around the motor cap and across the front of the machine to add needle bar tension. It is recommended that you use Thick Rubber Bands and Dan's Perfect Nipples.

• Cartridges: wrap a rubber band around the motor cap and over the top of the armature bar to counteract the cartridge's upward tension. Thick or standard rubber bands both work, it will just depend on the tension of the cartridge membrane or band to determine with rubber band provides the proper counter resistance.

Description:

The most significant update to the V3/24 Sidewinder is the added (and optional) Needle Bar Tensioner. This added tensioner eliminates the need to use a Rubber Band, improving all around machine performance and results. Tensioner reduces spitting and increases power. These machines can be used with or without the Tensioner, it is detached by simply removing the thumbscrew and taking it off the machine.

Aside from the added Needle Bar Tensioner, this new version of remastered V3 Sidewinder is dialed in and updated with various improvements to increase machine longevity and consistency.

The V3/24 follows the same concept as the past V3r, but with a focus on what makes a Sidewinder a Sidewinder.  Hard hitting, effortless, and zippy.  -Intended for experienced artists who don’t want to mess around.

Made in the USA!

DK Machines sold by Workhorse are engineered and designed by Dan. Parts are milled in his authorized and trusted machine shop, then assembled by DK certified trained technicians at the Workhorse facility in Michigan. All Sidewinders go through rigorous QC checks and are all ran through our testing machine to lightly break in. One year warranty on all models. All current Sidewinders are serviced by Workhorse, some older models are serviced by Dan or one of his certified technicians found on his website.

Highlights:

• CNC Cut Iron Cracker Liner Frame with Lightened / Drilled out Upright
• Custom Slide Vise with Inlaid Insert
• Polished Nickel Chromed-out Finish
• Blackened Deluxe Hardware PLUS Custom Dice Contact

• 8 Wrap 1" Custom Coils

Specifications:

• Medium Speed with a Hard Hit
• Great Liner for Traditional Work
• 130-135 Hz. @ 6 V unloaded
• Pushes 5s to 11s with Ease


Made in the USA
