Official DK Thumbscrew

8-32 Thread, Full 5/8" Length, compatible with most Kubin Vise Styles.

Ghost Dog Revival Binder Set

High grade steel, precision milled to trade standard measurements of 0.625" length and 0.325" diameter. Rear Binder is designed for vertical use.

Each set includes the steel front binder, brass DK drilled screw with hex nut, steel washers, fiber washers, screws, nylon bead, and GDR hex head copper contact screw with a hex allen key.

6 Layer coils

• One Pair
• Hand wrapped

• Not soldered
• No Capacitor.

  Available as 1.25" Full Size and 1.125" Coils.

8 Layer coils

• One Pair
• Hand wrapped
• Not soldered
• No Capacitor.

  Available as either 1" Mini Coils, 1.125" Coils or 1.25" Full Size Coils.

Deluxe Workhorse Armature Bar Fixture Set!

This is a very simple, yet effective tool used by our builders and many others. The perfect tool to easily attach springs to your a-bar while ensuring all parts are kept parallel and straight.

Deluxe Fixture works for 1/2" rear springs. It comes with or without our high-quality alignment tool and comes standard with a hole in the base to hold the tool and use the fixture as a machine stand, freeing up both hands for repairs.

Armature Bar Fixture Specs:

• Hardened Steel Base and Top Brackets to Ensure Years of Use
• Standard 1/2" Wide Slot for Rear Springs
• Standard 3/8" Wide Slot For Armature Bars
• 1" x 3" Overall Part Dimensions
• Insert Alignment Tool in hole to use as a stand to help hold your machine while working on it

Alignment Tool Specs:

• 5/16" x 3.5" Stainless Bar
• Knurled Grip
• Armature Bar Nipple Slot on the top for alignment use
• Armature Bar Groove inside for tweaking / turning your a-bar if necessary.... we highly recommend that only those experienced with machine building and repair use the tweak option....it is not always necessary and not always the best way to make things hit flat, just one of many options.

Additionally:

• These are must haves for machine building and machine repair
• As always, all parts made in the USA
• Skills nor machine are included, sorry


Soldered 6 Wrap Coils

6 layer coils hand wrapped, soldered with 47 uf capacitor and lugs.

Available as 1.25" Full Size and 1.125" Coils

Soldered 8 Wrap Coils

8 layer coils hand wrapped, soldered with 47 uf capacitor and lugs.

Available as either 1" Mini Coils, 1.125" or 1.25" Full Size Coils

10 layer coils hand wrapped, soldered with 47 uf capacitor and lugs.

Available as either 1" mini coils or 1.25" full sized coils.

Deluxe Spring Set

The Mixed Spring Set Includes:

• 16 Rears (4- Short .018", 4- Long .018", 4- Short .02", 4- Long .02")
• 18 Fronts - (3- Short .018", 6- Medium .018", 3- Long .018", 2- Short .02", 2- Medium .02", 2- Long .02") Total of 34 individual springs.

 The 18 Gauge Set Includes:

• 16 Rears (8- Short .018", 8- Long .018")
• 16 Fronts (4- Short .018", 8- Medium .018", 4- Long .018") Total of 32 individual springs.

**18's and 20's now come with a front hole punched in the rear spring and a slotted rear hole for a universal fit**

New Swing Gate Replacement Tube Vise!

• CNC Milled Low Carbon Steel

• Spring Loaded Swing Gate Vise designed by Seth Ciferri

• Slotted Coil Holes for Adjust-ability to Fit Most Any Frame

• Durable Black Zinc Finish

• Comes with Swing Arm, Thumbscrew, Various Length Torx Coil Screws to Account for Base Thickness, plus Extra Swing Arm Springs

Dan Kubin Needle Bar Tensioner

The most significant update to the V3/24 Sidewinder is the added (and optional) Needle Bar Tensioner. This added Tensioner eliminates the need to use a Rubber Band, improving all around machine performance and results. Tensioner reduces spitting and increases power.

The V3/24 Tensioner can be used on all versions of Dan Kubin V3Rs, 2019 to 2024.

Needle Bar Tensioner Specifications:

• Lightweight Aerospace Aluminum Arm with precision made custom bearing
• Creates necessary needle bar tension for stability, eliminating the need to use a Rubber Band
• Moves forward and backwards, in and out of position easily by loosening and tightening the thumbscrew
• When setting up your needle and tube, position Needle Tensioner in desired position depending on the amount of tension you want to add to the needle bar.
• Adjust position by loosening the thumbscrew, pull arm back and then tighten when you reach desired tension.

Upgrade Step by Step:

1. Loosen and remove the thumbscrew
2. Insert thumbscrew into hole in Needle Bar Tensioner
3. Re-insert thumbscrew into frame with Tensioner bearing facing inwards (see picture)
4. Ensure Vise Slide is in correct position, so the thumbscrew easily threads into Slide
5. Tighten with Needle Bar Tensioner in desired position

**OG V3R and V3/23 SPECIAL NOTE - Use of this Tensioner instead of Rubber Bands will noticeably increase the strength of your machine. If it is hitting too hard using the Needle Bar Tensioner, simply adjust your voltage and turn the machine down and adjust stroke wheel setting as needed to accomplish desired speed / hit.

10% OFF DISCOUNT APPLIES IN CART!  No Code Needed.

Specifications:

• CNC Cut Iron Frame

• Designed by Seth Ciferri

• Red Oxide Finish
• Geometry for 1" Coils
• Drop Down Rear End and Drop Down Vise Allowing More Space While Maintaining Mini Geometry


Made in the USA

Model 6 Liner Frame

Specifications:

• CNC Cut Iron Liner Frame

• Designed by Marv Lerning, inspired by the classic Waters Model 6
• Black Zinc Finish
• Geometry for 1.25" Coils
• Standard Pinch Vise
• Weighs 2.9 oz

Made in the USA

Model 6 Shader Frame

Specifications:

• CNC Cut Iron Shader Frame

• Designed by Marv Lerning, inspired by the classic Waters Model 6
• Black Zinc Finish
• Geometry for 1.25" Coils
• Standard Pinch Vise
• Weighs 3.10 oz

Made in the USA

Workhorse A1 Slideback Tattoo Machine Frame

Components:

• CNC Cut Iron Frame

• Designed by Mike Pike, modeled off a classic A1 Tattoo Machine

• Raw Finish ready for paint, powder coat, plating or oxide

• Geometry for 1.25" Coil Liner or Shader

• Swing Gate Vise with extra screws to work with 1.25" coils or with a yoke and 1" coils

• Weighs 2.8 oz

*Frame and Swing Gate Vise parts only, no other parts or tools included.

Made in the USA
